Main Functions

1,Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.
2,Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high temperature.
3,Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It provides sufficient steady high pressure to bloww large irregular shape bottles.
4,Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.
5,Operated step-by-step and in semi-auto maode.
6,Wide-mouth jar and hot-fill bottles can also be made.

Main Technical Parameters

Voltage	220-380/50-60V\HZ
Power	12KW
Clamping force	90KN
High pressure Compressor  M3/Mpa	>=0.70/3.0×1set 22KW
Mould opening stroke (adjustable)	200MM
Max.mould thickness	160-240MM
Main body dimension(L×W×H)	1.45×0.6×1.75M
Main body weight	0.6T
